Glandless Piston Valve

Glandless Piston Valve
Glandless Piston Valve
Product Code : 10
Product Description
Glandless Piston Valve, also called a zero leak isolation Piston Valve, has lower and upper sealing rings with a piston as a replacement of seat and gland. All difficulties linked to the conventional seats replacement are overcome. This valve is suitable option to prevent inline leakage and leakage through glands. It can make for leak-proof isolation in the pipelines.
As it is a seat less and gland less piston valve, there are piston and sealing rings as it's heart. A leak proof shutoff is achieved by sealing of a burnished piston seals against SS reinforced graphite rings. Its design ensures a long life even at temperatures up to 427 degrees Celsius.
There is a piston valve stem and hand wheel connected to a burnished piston. A lantern bush separates two sealing rings between which the piston passes through. These sealing rings are Stainless steel reinforced graphite, featuring sustaining compression exerted by Bonnet & giving soft seal against piston. The upper sealing ring is like a conventional gland packing that prevents the leakage towards atmosphere. The lower sealing ring is like a seat that prevents in line leakage. Both, upper and lower rings are separated with a lantern bush and also allows flow through the Piston Valve.

Features :

  • Larger and effective sealing area
  • Durability as the piston is not exposed to media
  • Self Lubricating and Self Cleaning
  • No Gland & Seat
  • Leak proof isolation - Class 6 shut off achieved
  • Maintenance friendly
  • Uniform sealing rings on both the sides
  • User Friendly
  • It does not need Piston Valve Key
  • Scrap Free Piston Valve
  • Process can be executed without removing the Piston Valve from pipeline.
Ranges :

Forged Carbon Steel  (A105) with Stainless Steel Internals
15, 20, 25, 32 and 40 NB in socket weld ends and Screwed NPT/ BSPT Ends

For socket weld ends,
Maximum Operating Pressure : 78 kg/cm2
Cold Hydraulic test pressure : 156 kg/cm2
Maximum Operating Temperature : 427 degrees Celsius

For screwed Ends,
Cold Hydraulic test pressure : 63 kg/cm2
Maximum Operating Pressure : 31.64 kg/cm2
Maximum Operating Temperature : 427 deg C

Cast Carbon Steel (ASTM A 216 WCB ) with Stainless Steel Internals
50, 65, 80, 100, 125, 150 ans 200 NB in Flanged ends with ANSI CL.300
Max working conditions :39.5 kg/cm3 at 300 degrees Celsius
Body design conditions : 42 kg/cm2 at 427 degrees Celsius
Cold Hydraulic test pressure : 79 kg/cm2

  • ANSI B 16.34 , API 598, API 602 ,IBR / N IBR

The FM Piston valve is perfect for on-off duties for:
  • Alkalies
  • Steam
  • LPG
  • Acids
  • Thermic Fluids
  • Ammonia
  • FM PISTON VALVE is energy saving isolation valve, that prevents all kinds of valve leakages and increases the life of the valve. The gland less & seat less valve is a solution to problems arising from seat & gland packing.
  • There are piston and sealing rings in the FM piston valve. A burnished piston against SS reinforced graphite rings provides leak proof shutoff, ensuring longer life even at temperatures up to 427 degrees Celsius.
  • Operation of this valve requires a little effort. There is no need for any valve key to tighten the valve.
  • Easy and quick maintenance, which minimizes the plant downtime.
